General Specifications
Patent Number 8235427, 7815225, 7328493
| Material: | Ductile Iron per ASTM A536 |
| Pressure: | 350 psi. Rating for sizes 4" through 12" |
| Testing: | In accordance with ANSI/AWWA C153/A21.53 and UL and FM requirements (pending) |
| Laying Length: | In accordance with ANSI/AWWA C153/A21.53 (fittings not listed in AWWA C153 have dimensions per RCT design) |
| Deflection: | 4" through 12" full 5° degrees after assembly |
| Weights: | Are in pounds |
| Flanges: | All flange ends meet ANSI/AWWA C115/A21.15 and ANSI B16.1 class 125 |
| Coating: | Fusion Bonded Epoxy coating both internal and external; NSF |
| Gaskets: | S BR in accordance with ANSI/AWWA C111, NSF 61 |
| Approvals: | Underwriters Lavatories Listed and Factory Mutual Approval (pending) |
| Dimensions: | All dimensions are in inches unless noted otherwise |
Standards
Meets or Exceeds Applicable Requirements of the Standards Listed Below
- ANSI/AWWA C153/A21.53 "American National Standard for Ductile Iron Compact Fittings, 3-inch through 24-inch, and 54-inch through 64-inch for Water Service."
- ANSI/AWWA C111/A21.11 "American National Standard for Rubber Gasket Joints for Ductile Iron Pressure Pipe and Fittings."
- ANSI/AWWA C116/A21.16 "American National Standard for Protective Fusion Bonded Epoxy Coating for the Interior and Exterior Surfaces of Ductile Iron and Grey Iron Fittings for Water Supply Service."
- ASTM F1674 "Standard Test Method for Joint Restraint Products for Use with PVC Pipe."
- ASTM D3139 "Standard Specification for Joints for Plastic Pressure Pipes Using Flexible Elastomeric Seals"
- ASTM F477 "Standard Specification for Elastomeric Seals (Gaskets) for Joining Plastic Pipe"
- Underwriters Labratories Listed (pending)
- Factory Mutual Approved (pending)
